Signal Isolator/Repeater DC to DC Signal – ISM-12-1-3 (L)

Name: Signal Isolator/Repeater DC to DC Signal - ISM-12-1-3 (L)
SKU: 4716
Price: 4463 INR
Availability: InStock

₹4,463

Prices are inclusive of Delivery Charges.

ISM-12-1-3 (L) – Single input & 3 outputs operating on 24VDC (18-36)VDC

Select Part No

Clear

Key Features

Accepts DC signal inputs and provides optically isolated proportional analogue output.
On site calibration facility-using ZERO/SPAN presets.
Operates on 230VAC or 24VDC (18-36) VDC.
Designed using ultra low drift components for long term stability.

The interface of low-level signals coming from the sensors or transducers from the plant to DCS, SCADA, PLC or PID process controllers without ground line interferences.
Signal multiplier – single input and 2 to 4 outputs.

Parameters	Description
Input	1) DC input - DC current or voltage (4-20Ma)/0-5V/0-10V
	2) Frequency input DC levels of clock pulses of max. 10KHZ. @ (12-24)VDC
Range	Absolute
Output	(4-20) mA, (0-5)VDC, (0-10) VDC
	For current output, RL (max.) = 500 Ohms.
	For voltage output, RL (min) = 100K Ohms.
No of Outputs	1 to 4 (as specified by the model)
Accuracy	Absolute to the input
Calibration	On site calibration facility through ZERO and SPAN presets accessible to the user.
Isolation	Input and Output are optically isolated. Power supply is also isolated from Input and Output.(3 way isolation)
Isolation Voltage	Greater than 1 KV.
Mounting	35-mm. DIN rail mounting ABS enclosure.
Supply	DC Supply : 24VDC (18-36)VDC
Size	45 x 75 x 110

Sr. No.	Specifications	Part No.
Single Input and Three Output - ISM-12-1-3 (L)
1.1	Input : 4-20mA Output : 3 x 4-20mA	2016-1-1
1.2	Input : 4-20mA Output : 3 x 0-5V	2016-1-2
1.3	Input : 4-20mA Output : 3 x 0-10V	2016-1-3
1.4	Input : 0-5V Output : 3 x 4-20mA	2016-1-4
1.5	Input : 0-5V Output : 3 x 0-5V	2016-1-5
1.6	Input : 0-5V Output : 3 x 0-10V	2016-1-6
1.7	Input : 0-10V Output : 3 x 4-20mA	2016-1-7
1.8	Input : 0-10V Output : 3 x 0-5V	2016-1-8
1.9	Input : 0-10V Output : 3 x 0-10V	2016-1-9
